| ENGINE |
|
| Engine Type |
4-stroke parallel twin engine, four valves per cylinder, double overhead camshafts, dry sump lubrication |
| Cooling System |
Liquid cooled |
| Bore |
84 mm |
| Stroke |
77 mm |
| Displacement |
853 cc |
| Engine Power |
90 hp (66 kW) at 8,000 rpm |
| Engine Torque |
63 lb-ft (86 Nm) at 6,250 rpm |
| Compression Ratio |
12.7-1 |
| Emissions |
Control |
| Top Speed |
118 mph |
| Fuel Type |
Premium Unleaded |
| Fuel Economy - Combined City/Hwy |
57 mpg (WMTC) |
| Alternator |
Three-phase 416 W generator |
| Battery |
12 V / 10 Ah, maintenance-free |
| DRIVETRAIN |
|
| Clutch |
Multi-plate wet clutch, mechanically operated |
| Gearbox |
Constant-mesh 6-speed gearbox with straight cut gears |
| Drive System |
Chain drive |
| Frame Type |
Tubular steel space frame, load bearing engine |
| Front Suspension |
Telescopic fork, 41 mm |
| Rear Suspension |
Cast aluminum 2-sided swing arm, central spring strut, spring pre-load hydraulically adjustable (continuously variable) at handwheel, rebound damping adjustable |
| BRAKES/WHEELS/TIRES |
|
| Front braking system |
Dual floating disc brakes, dual-piston floating calipers, diameter 305 mm |
| Rear braking system |
Single disc brake, diameter 265 mm, single-piston floating caliper |
| ABS Option |
BMW Motorrad ABS (can be switched off) |
| Wheels |
Wire spoke wheels |
| Front Wheel Travel |
6.7 in (170 mm) |
| Rear Wheel Travel |
6.7 in (170 mm) |
| Front Wheel |
2.50 x 19 in |
| Rear Wheel |
4.25 x 17 in |
| Front Tire |
110/80 - 19 |
| Rear Tire |
150/70 - 17 |
| DIMENSIONS |
|
| Wheelbase |
61.4 in (1,559 mm) |
| Castor |
4.1 in (104.5 |
| Steering |
63° |
| Length |
88.8 in (2,255 mm) |
| Width |
36.3 in (922 mm) |
| Height |
48.2 in (1,225 mm) |
| Seat Height |
32.1 in |
| Fuel Capacity |
4.0 gal (15 l) |
| Fuel Reserve |
Approx. 0.9 gal (3.5 l) |
| Payload Capacity |
476 lbs (216 kg) |
| Weight |
493lbs (224 kg) |
