| ENGINE |
|
| Engine Type |
4-stroke, four valves per cylinder, two overhead camshafts |
| Cooling System |
Water-cooled |
| Bore |
86 mm |
| Stroke |
77 mm |
| Displacement |
895 cc |
| Engine Power |
99 hp at 8,500 rpm |
| Engine Torque |
68 lb-ft at 6,750 rpm |
| Compression Ratio |
13.1-1 |
| Emissions |
Closed-loop 3-way catalytic converter, emission standard EU-5 |
| Top Speed |
130 mph |
| Fuel Type |
Premium Unleaded |
| Fuel Economy - Combined City/Hwy |
56 mpg (WMTC) |
| Alternator |
Permanent magnetic alternator 416 W (nominal power) |
| Battery |
12 V / 12 Ah, maintenance-free |
| DRIVETRAIN |
|
| Clutch |
Multiple-disc wet clutch (anti hopping), mechanically operated |
| Gearbox |
Constant mesh 6-speed gearbox integrated in crankcase |
| Drive System |
Endless O-ring chain with shock damping in rear wheel hub |
| Frame Type |
Bridge-type frame, steel shell construction |
| Front Suspension |
Upside-down telescopic fork, 43 mm |
| Rear Suspension |
Cast aluminum dual swing arm, central spring strut, spring pre-load hydraulically adjustable, rebound damping adjustable |
| BRAKES/WHEELS/TIRES |
|
| Front braking system |
Dual disc brake, floating brake discs, 320 mm, 4-piston radial brake calipers |
| Rear braking system |
Single disc brake, 265 mm, single-piston floating caliper |
| ABS Option |
BMW Motorrad ABS |
| Wheels |
Cast aluminum wheels |
| Front Wheel Travel |
6.7 in (170 mm) |
| Rear Wheel Travel |
6.8 in (172 mm) |
| Front Wheel |
3.50 x 17 in |
| Rear Wheel |
5.50 x 17 in |
| Front Tire |
120/70 ZR 17 |
| Rear Tire |
180/55 ZR 17 |
| DIMENSIONS |
|
| Wheelbase |
60 in (1,521 mm) |
| Castor |
4.1 in (105.2 mm) |
| Steering |
60.5° |
| Length |
85.0 in (2,160 mm) |
| Width |
33.9 in (860 mm) |
| Height |
52.0 in - 55.9 in (1,320 mm - 1,420 mm) |
| Seat Height |
32.5 in |
| Fuel Capacity |
4.1 gal (15.5 L) |
| Fuel Reserve |
Approx. 1 gal (3.5 L) |
| Payload Capacity |
483 lbs (219 kg) |
| Weight |
482 lbs (219 kg) |
