| ENGINE |
|
| Engine Type |
4-stroke in-line 6-cylinder engine, two overhead camshafts, four valves per cylinder |
| Cooling System |
Oil-/watercooled |
| Bore |
72 mm |
| Stroke |
67.5 mm |
| Displacement |
1,649 cc |
| Engine Power |
160 hp (118 kW) at 6,750 rpm |
| Engine Torque |
132.7 lbs-ft at 5,250 rpm |
| Compression Ratio |
12.2-1 |
| Emissions |
Closed-loop 3-way catalytic converter, emission standard EU-4 |
| Top Speed |
100 mph |
| ELECTRIC |
|
| Alternator |
Three-phase alternator with 700 W (nominal power) |
| Battery |
12 V / 16 Ah |
| DRIVETRAIN |
|
| Clutch |
Multiple-disc clutch in oil bath |
| Gearbox |
6-speed, helical, gearbox |
| Drive System |
Shaft drive 2.75-1 |
| CHASSIS/ SUSPENSION/ BRAKES |
|
| Frame Type |
Bridge-type frame, cast aluminum, load-bearing engine |
| Front Suspension |
BMW Motorrad Duolever; central spring strut |
| Rear Suspension |
Cast aluminum single-sided swing arm with BMW Motorrad Paralever; central spring strut |
| Front braking system |
Dual disc brake, diameter 320 mm, 4-piston fixed calipers |
| Rear braking system |
Single disc brake, diameter 320 mm, double-piston caliper |
| ABS Option |
BMW Motorrad Integral ABS Pro (part-integral, slant-layer-optimized) |
| WHEELS / TIRES |
|
| Wheels |
Aluminum cast wheels |
| Front Wheel Travel |
4.5 in (115 mm) |
| Rear Wheel Travel |
5.3 in |
| Front Wheel |
3.50 x 17 in |
| Rear Wheel |
6.00 x 17 in |
| Front Tire |
120/70 ZR 17 |
| Rear Tire |
190/55 ZR 17 |
| DIMENSIONS |
|
| Wheelbase |
63.7 in (1,618 mm) |
| Castor |
4.2 in (106.4 mm) |
| Steering |
62.2° |
| Length |
100.8 in |
| Width |
39.4 in |
| Height |
56.7 in |
| Seat Height |
29.5 in |
| Fuel Capacity |
7.0 gal (26.5 l) |
| Fuel Reserve |
Approx. 1 gal (4 l) |
| Payload Capacity |
425.5 lbs |
| Weight |
809.1 lbs |
