| ENGINE |
|
| Engine Type |
Two-cylinder four-stroke boxer engine with two chain-driven camshafts above the crankshaft. |
| Cooling System |
Air/oil cooled |
| Bore |
107.1 mm |
| Stroke |
100 mm |
| Displacement |
1,802 cc |
| Engine Power |
91 hp at 4,750 rpm |
| Engine Torque |
116 lb-ft at 3,000 rpm |
| Compression Ratio |
9.6-1 |
| Emissions |
Regulated three-way catalytic converter |
| Top Speed |
111 mph |
| Fuel Type |
Premium Unleaded |
| Alternator |
Permanent magnet generator 600 W (nominal capacity) |
| Battery |
12 V / 26 Ah, maintenance-free |
| DRIVETRAIN |
|
| Clutch |
Single-disk dry clutch |
| Gearbox |
6-speed transmission |
| Frame Type |
Double-cradle steel frame |
| Front Suspension |
Telescopic fork |
| Rear Suspension |
Steel swingarm with central shock strut |
| BRAKES/WHEELS/TIRES |
|
| Front braking system |
Twin disc brakes, diameter 300 mm, 4-piston fixed caliper |
| Rear braking system |
Single disc brake, diameter 300 mm, fixed caliper |
| ABS Option |
BMW Motorrad Integral ABS (partially integral) |
| Wheels |
Spoked wheel |
| Front Wheel Travel |
4.7 in |
| Rear Wheel Travel |
3.5 in |
| Front Wheel |
3.00 x 16 in |
| Rear Wheel |
5.00 x 16 in |
| Front Tire |
130/90 B16 |
| Rear Tire |
180/65 B16 |
| DIMENSIONS |
|
| Wheelbase |
68.1 in |
| Castor |
5.9 in |
| Steering |
57.3° |
| Length |
96.1 in |
| Width |
38.0 in |
| Height |
96.1 in |
| Seat Height |
28.0 in |
| Fuel Capacity |
4.2 gal |
| Fuel Reserve |
Approx. 0.9 gal (3.5 L) |
| Weight |
805 lbs |
