| ENGINE |
|
| Engine Type |
Four-cylinder four-stroke in-line engine with four valves per cylinder |
| Bore x Stroke |
3.15 in x 1.96 in |
| Displacement |
999 cc |
| Top Speed |
Max - 188 mph |
| Engine Power |
205 hp at 13,000 rpm |
| Engine Torque |
83 lb-ft at 11,000 rpm |
| Compression Ratio |
13.3 to 1 |
| Emissions |
Closed-loop three-way catalytic converter |
| Alternator |
450 W |
| Battery |
12 V / 8 Ah, maintenance-free |
| DRIVETRAIN |
|
| Clutch |
Multiplate clutch in oil bath, anti-hopping clutch, with self-reinforcement |
| Gearbox |
Claw-shifted 6-speed gearbox with straight cut gears |
| Drive System |
Chain 525 17/46 |
| SUSPENSION |
|
| Front Suspension |
Upside-down telescopic fork with a diameter of 45 mm, spring preload and adjustable rebound and compression stage |
| Rear Suspension |
Aluminum swingarm, central shock absorber, adjustable rebound and compression damping and adjustable spring preload |
| Front Travel (in./cm.) |
4.7 in |
| Rear Travel (in./cm.) |
4.6 in |
| BRAKES/WHEELS/TIRES |
|
| Front braking system |
Twin disc brake, Ø 320 mm 4.5 mm, radial 4-piston fixed caliper (5 mm M wheels) |
| Rear braking system |
Single disc brake, diameter 220 mm, 1-piston floating caliper |
| ABS Option |
BMW Motorrad BMW Motorrad Race ABS (partial integral), Brake-Slide-AssistABS, partial integral |
| Wheels |
Cast aluminum |
| Front Wheel |
3.50 x 17 |
| Rear Wheel |
6.00 x 17 |
| Front Tire |
120/70 ZR 17 |
| Rear Tire |
190/55 ZR17 (with M wheels |
| DIMENSIONS |
|
| Wheelbase |
57.4 in |
| Inner Leg Curve |
72.6 in |
| Castor |
3.93 in |
| Steering |
Head Angle - 66.4° |
| Length |
81.6 in |
| Width |
33.4 in |
| Height |
47.4 in |
| Seat Height |
32.4 in |
| Dry Weight |
385.8 lbs (M Package 382.0 lbs without battery) |
