| ENGINE |
|
| Engine Type |
L-Twin, Desmodromic distribution, 2 valves per cylinder, air cooled |
| Displacement |
803 cc |
| Bore x Stroke |
88 x 66 mm |
| Compression Ratio |
11 to 1 |
| Power |
73 hp (53.6 kW) @ 8,250 rpm |
| Torque |
48.1 lb-ft (65.2 Nm) @ 7,000 rpm |
| TRANSMISSION |
|
| Gearbox |
6 speed with Ducati Quick Shift up/down |
| Ratio |
Straight cut gears, Ratio 1.85 |
| Final Drive |
Chain, front spocket 15, rear sprocket 46 |
| Clutch |
Hydraulically controlled slipper and self-servo wet multiplate clutch |
| CHASSIS |
|
| Frame |
Tubular steel Trellis frame |
| Front Suspension |
Upside down Kayaba 41 mm fork |
| Rear Suspension |
Kayaba rear shock, pre-load adjustable. |
| Front Wheel |
Light alloy 3.00 x 18 in |
| Rear Wheel |
Light alloy 5.50 x 17 in |
| Front Tire |
Pirelli MT 60 RS 110/80 R18 |
| Rear Tire |
Pirelli MT 60 RS 180/55 R17 |
| Front Brake |
Ø330 mm disc, radial 4-piston caliper with Bosch Cornering ABS as standard equipment |
| Rear Brake |
Ø245 mm disc, 1-piston floating caliper with Bosch Cornering ABS as standard equipment |
| DIMENSIONS |
|
| Wet Weight no fuel |
401 lb (182 kg) |
| Seat Height |
31.3 in (795 mm) |
| Wheelbase |
57 in (1,449 mm) |
| Fuel Tank Capacity |
3.83 US gal (14.5 l) |
| Number of Seats |
2 |
