| FRAMESET |
|
| Frame Type |
29-inch, Carbon, Integrated battery, Boost, 160 mm |
| Fork |
DVO Onyx D1CV OTT, Air, 170 mm, tapered |
| Shock |
DVO JadeX CV Coil, Coil, 205x65 mm |
| BRAKES / DRIVETRAIN |
|
| Motor |
SRAM Eagle Powertrain Drive Unit, 250 W, 90 Nm |
| Battery |
SRAM Eagle Powertrain, 630 Wh |
| Charger |
SRAM Eagle Powertrain Charger, 4 A |
| Cassette / Chain |
SRAM XS-1295, 10-52 T / SRAM GX Eagle Transmission Flattop |
| WHEELS |
|
| Front Wheel |
Rim - Mach 1 TRUCKY 30, With eyelets, Tubeless ready / Hub - GASGAS DA210F, 6-hole, 15x110 mm, thru axle |
| Rear Wheel |
Rim - Mach 1 TRUCKY 30, With eyelets, Tubeless ready / Hub - GASGAS DA210R, 6-hole, 12x148 mm, thru axle |
| Front Tire |
Maxxis Assegai, 63-622, 29 x 2.5 |
| Rear Tire |
Maxxis Minion DHR II, 62-622, 29 x 2.4 |
| COCKPIT |
|
| Stem |
GASGAS 35, 0 °, Ahead |
| Handlebar |
GASGAS Riser 35 mm, 780 mm, Sweep |
| Saddle |
Selle San Marco GND |
| DIMENSIONS |
|
| Weight |
24.4 kg |
| Permissible total weight |
130 kg |
